Mulching Heads

FAE UMM/EX

ASK A QUESTION Call Van-Ed Equipment
Have a question?
Give us a call: 604-888-9020
Fill out a contact request

Carrier

  • Tonnes

    20 to 36

Key Specs

  • Shredding Diameter

    Ø 40 cm max

  • Flow Rate

    from 130 to 300 L/min

Product Overview

Available in the following versions: UMM/EX/VT, UMM/EX/SONIC, UMM/EX/HP/VT, UMM/EX/HP/SONIC

The UMM/EX/VT – UMM/EX/SONIC – UMM/EX/HP/VT – UMM/EX/HP/SONIC mulchers are great for mulching vegetation and trees with a max. diameter of 40 cm and are compatible with excavators from 20 to 36 t. Their hydraulic capacity ranges from 130 to 300 L/min.
The models are recommended for managing and controlling vegetation in wooded areas, maintaining green spaces, and anywhere a large mulching capacity is required.
The line offers two types of hydraulic motors: the VT motor with automatic variable displacement and increased torque and the SONIC motor, a FAE exclusive that optimizes performance and can be easily managed using the dedicated FAE App for smartphone.
The Poly Chain belt transmission guarantees optimum power transfer and reliability over time. The bolted counter blades work to finely mulch the material being processed and make maintenance easier.
Its strong steel structural frame guarantees excellent reliability over time. The mulching chamber also features welded protections made of an anti-wear material.
The large type “C” rotor that comes standard lets you attach different tooth models designated for various types of vegetation and uses.  The rotor also comes with side teeth, which help keep the crushing chamber clean at all times.

Poly Chain Belt Transmission (Vt Only)
For Optimum Power Transfer

Bolted Counter Blades
For Fine Mulching And Easy Maintenance

Flow Control Valve
Protects The Hydraulic Motor

Vt Motor
Automatic Torque Increase

Diverter Valve (Sonic)
For Hydraulic Control Of The Hood

Sonic (Umm/ex/vt – Umm/ex/sonic – Umm/ex/vt/hp – Umm/ex/hp/sonic)
Sonic Is A New Automatic Intelligent System That Manages The Hydraulic Transmission

  • Hydraulic rear hood
  • FCP wear-resistant clad plates
  • Enclosed, dust-resistant machine body
  • Motor enclosed in the frame
  • Interchangeable bolt-on counter blades
  • Fittings for hydraulic connections
  • Bolt-on interchangeable protection chains
  • Additional reinforced side plates (UMM/EX/HP)
  • Timing belt transmission
  • 110 cc SONIC hydraulic piston motor (UMM/EX/SONIC)
  • 110 cc VT hydraulic piston motor (UMM/EX/VT)
  • 160 cc SONIC hydraulic piston motor (UMM/EX/HP/SONIC)
  • 160 cc VT hydraulic piston motor (UMM/EX/HP/VT)
  • Flow Control valve with integrated relief and anti-cavitation valves
  • 12V diverter valve (UMM/EX/SONIC – UMM/EX/HP/SONIC)
  • Sonic System (UMM/EX/SONIC – UMM/EX/HP/SONIC)
  • Interchangeable forged steel rotor shafts
  • Rotor with teeth C/3
  • Control box for diverter valve (UMM/EX/SONIC – UMM/EX/HP/SONIC)
